Bossberg frame set
$ 2,195.00
Description
The Flanders Bossberg 29er is our new dual suspension Mountain bike evolved from our Berg hardtail. The Bossberg has been designed with optimum geometry to give maximuim speed and comfort. Features include Boost axles 110×15 front and 148×12 rear, 48* head tube, 46mm offset. Rear suspension is 100mm and front suspension options are 100mm and 120mm. Complete internal cable routing makes for a clean design and will maintain optimal gear shifting in adverse conditions. Our sizing options are 15.5”, 17.5”, 19”, 21”. Our frame set includes head set, rear thru axle with the option to include the rear shock.
Specifications and Custom Options
| Frame: | Uni directional monocoque carbon frame for 29″ wheels, fully integrated gear and brake cables, tapered head tube (1 1/8 ” – 1 1/2”), 160mm front and rear disc brake rotors, front axle 100x15mm, rear axle 148x12mm, race refined geometry | ||
| Frame Sizes: | Small (15.5″), Medium (17.5″), Large (19″), X Large (21″) | ||
| Frame Colour: | Gloss Black | ||
| Suspention | Monarch RT3 | ||
Geometry
| Size | Small | Medium | Large | X Large |
|---|---|---|---|---|
| Seat Tube (mm) | 410 | 445 | 483 | 530 |
| Effective TT (mm) | 580 | 600 | 620 | 640 |
| Head Tube (mm) | 100 | 105 | 120 | 135 |
| Head Tube (deg) | 68 | 68 | 68 | 68 |
| Seat Tube (deg) | 73.8 | 73.8 | 73.8 | 73.8 |
| BB Drop (mm) | 40 | 40 | 40 | 40 |
| Chainstay (mm) | 438 | 438 | 438 | 438 |
| Reach (mm) | 409 | 428 | 448 | 469 |
| Stack (mm) | 585 | 590 | 605 | 621 |
| Wheelbase (mm) | 1117 | 1137 | 1157 | 1177 |
